DEEP BLUE 115'

The Deep Blue 115, a genuine explorer yacht in a compact package, mirrors qualities and comfort of the larger models of the line it belongs to. Crafted for extensive navigation, this explorer yacht offers remarkable indoor and outdoor living spaces, ensuring spacious accommodations for Owners, guests, and crew alike. Large openable doors ensure continuity between interior and exterior areas on both the Main and Upper deck creating bright and airy environments.

Specifications

Length overall

35.00 m

114,8 ft

Waterline length

32.80 m

107,6 ft

Max beam

7.55 m

24,8 ft

Depth, amidship

4.00 m

13,1 ft

Draught, full load under the keel

2,45 m

8,00 ft

Displacement, full load

325 t

Classification

RINA C ✠ HULL • MACH Ych, Short Range Compilance with Malta Code

Exterior design

Horacio Bozzo

Diesel oil

45˙000 lt

11˙800 gal

Urea

1˙800 lt

475 gal

Fresh water

6˙000 lt

1˙585 gal

Black water

1˙000 lt

264 gal

Grey water

7˙000 lt

1˙849 gal

Clean oil / Dirty oil

350 / 350 lt

92 / 92 gal

Bilge

1˙100 lt

290 gal

Engines

2xCaterpillar C18 ACERT IMO tier III (533kW @1˙800-2˙100rpm)

Generator

2 x KOHLER / 55 ekW

Gearbox

2x REINTJES WAF 244 free standing - gear ratio 3,952:1

Generator

2x55 kW Kohler

Bow thruster

52 kW

Stabilizer fins

Electrical, Zero Speed

Maximum speed

13.5 Knots

Cruise speed

11.0 Knots

Range

5500 nm at 9.0 Knots

Passengers

10 (+2 Pullman Bed) p / 5 Cab

Crew

7 / 4 Cabins

DOWNLOAD SHORT SPECIFICATION

General Plan

SUN DECK
UPPER DECK
MAIN DECK
LOWER DECK
DOWNLOAD GENERAL PLAN
